Đầu dò, cảm biến, bộ hiển thị, bộ điều khiển, pH Meter – HAPH-6000

• Temperature compensation (within 0.1pH)
• Alarm alert : Abnormal operation (Calibration failure, Output range exceeded)
• Spontaneous display of pH and temperature

Specification

Transmitter
    • Measurement range
      pH 0.00~14.00 / Temperature -5 ~ +150℃
    • Minimum scale unit
      0.1pH, 0.1℃
    • Accuracy
      pH ±0.1 or less
    • Reproducibility
      pH ±0.1 or less
    • Temperature compensation
      pH ±0.1 or less
    • Output
      DC 0/4~20mA
    • Display
      LCD display (pH/temp. simultaneous display)
    • Alarm output
      22mA (Operation failure – electrode breakage, calibration failure, output range exceeded, etc.)
    • Power
      AC110/220V, 60Hz
    • Power consumption
      Maximum 7.5VA
    • Operating temp.
      -10~+55℃
    • Operating humidity
      RH 85% or less
    • Enclosure
      Display front part IP54 / Housing IP30
    • Size
      96(W) × 96(H) × 145(D) mm
    • Weight
      0.7kg
    • Housing material
      Polycarbonate
Sensor
    • Measurement range
      pH 0.00~14.00
    • Measurement method
      Combination glass electrode
    • Temperature range
      0~100℃
    • Electrode configuration
      Measuring electrode + comparison electrode + temperature compensation
