Water quality monitoring system of Online TN Analyzer – HATN-3000

HATN-3000 is an automatic measuring instrument for ultraviolet / visible spectroscopy of water pollution test method. In the pretreatment step, alkaline potassium persulfate is injected into the sample, heated at 90°C for 15 minutes, and irradiated with UV light to decompose organic and inorganic nitrogen compounds into nitrate ions. After cooling, hydrochloric acid is added to lower the acidity, and ultraviolet absorbance is measured at 220nm to measure total nitrogen. At this time, it is possible to measure more accurately by measuring the absorbance of the disturbance factor at 275nm to calibrate the measurement value. HATN-3000 is a new product of KORBI which not only shortens measuring time by adopting patented technology and newly-designed oxidation reaction chamber, but also has sophisticated design and user convenience.

Characteristics

HATN-3000
  • Adoption of oxidation reaction chamber with improved efficiency
  • Application of multi-channel valve for quantitative distribution of samples and reagents
  • Built-in user-oriented operating program with enhanced security function
  • Built-in functions to enhance user convenience

Specification

    • Measurement item
      Total Nitrogen (TN)
    • Measurement method
      UV Absorption photometry
    • Measurement range
      0~100mg/L (Adjustable)
    • Wavelength
      220nm (275nm for compensation)
    • Measurement interval
      30 minutes (Adjustable)
    • Detection limit
      1mg/L F.S.
    • Accuracy
      ±2% F.S.
    • Reproducibility
      ±2% F.S.
    • Linearity
      ±3% F.S.
    • Zero/Span drift
      ±2% F.S.
    • Oxidation method
      UV persulfate oxidation
    • Calibration
      Auto/manual calibration by standard solution
    • Sample/Reagent measuring method
      Step motor pulse control
    • Sample/Reagent distribution method
      8-port distribution control method (Fixed quantity injection with multi-channel valve system)
    • Operation system
      Windows 7 Pro
    • Output
      DC 4~20mA, RS-232C
    • Status display
      Normal operation, on calibration, error
    • Display
      Color LED 10.4″ (Touch screen)
    • Power
      AC 220V, 50/60Hz
    • Power consumption
      Average 70W
    • Voltage regulation
      3% or less
    • Data storage capacity
      HDD 100G or more
    • Data output
      USB terminal
    • Enclosure/Size
      Steel, 1.5T (Except paint) / 645(W) × 439(D) × 1600(H) mm
    • Operating humidity
      RH 95% or less
